Technical Data
Regulation Accuracy
+/- 0.5% Rated Steady State Conditions
Voltage Drift:
+/- 0.5% Voltage Change, for 50º C
Response Time: 1 Cycle
Operating Temperature: -30º C- +70º C
Exciter Field Resistance: 3.5Ω Min- 20Ω Max

Input/Output Data:
-Supply Voltage: 170~270v
-Power Supply: 1000 Va (Max)
-Power Dissipated: 30w ( Max )
-Voltage Sensing: 170~270v
-Output Voltage ( DC ) 80v
-Output Current ( DC ) 8a (Max, Continuos )
-Output Current ( DC ) 15a (Max Forcing One Minute)
